High Brightness LCD Module

55 inch High Brightness LCD Module(2000cd/㎡)

$860.00 1-49 pieces

$830 50-99 pieces

$800 ≥100 pieces

Payment Type：L/C,T/T,D/P,Paypal,Money Gram,Western Union

Incoterm：FOB,CFR,CIF,EXW,FCA,CPT,CIP

Transportation：Ocean,Land,Air

55 inches and above can be additionally provided with heat sink, special instructions are required: the module with heat sink increases the price.

Order online

Basic information	Type	CNSY-55-2000nitsoutdoor module
	Screen size	55 inch
	Working Temp	0-50℃
	Storage Temp	-20-60℃
	Environmental humidity	< 90% RH
Structural characteristics	Display scale	0.672916667
	Point spacing mm (H and V)	0.2485 * 0.7455
	Resolution	3840 * 2160
	Display area mm (H and V)	1024.4 * 578.6
	Visible area mm (H and V)	1214.6 * 685.4
	Appearance size mm (H and V thickness)	1248.6 * 719.6* 56
	backlight	LED backlight
	Display mode IPS	always black
Characteristic	Luminance(cd/㎡）	2000
	Brightness management	automatic sensitization
	Contrast ratio	4000: 1
	Display color	16.7M
	response time(ms)	8
	Viewing angle	178°/178°
Electronic characteristic	scanning frequency (Hz)	60
	Power (w)	280
	Supply voltage (V)	24
	Signal interface type	LVDS
	Optional	power board and image driver board
